The next generation TARUS Claymill

Refined from decades of expertise, the latest generation Claymill is a game changer delivering the best overall performance in the industry for sculpting car models.

TARUS took the legendary performance of the Claymill X and delivered it in a more compact form factor, perfect for any design studio environment.

With fastest production of Class-A surfaces and nearly silent operation, it maximizes productivity, allows you to produce more car models in the same time, while maintaining a peaceful work environment.

Our unique monocoque structure makes for a far more rigid machine than any comparable option. That allows Claymill to handle more power and stronger components which deliver the best surface finish and speed.

Better engineering design translates into durability and lower cost of ownership that TARUS Claymills are legendary for.

Claymill comes fully-featured including our Siemens SINUMERIK ONE-based TARUS Design Studio Interface and TPI CAM. Our proprietary Claymill interface is continually developed in partnership with design studios and renowned by car modellers worldwide. It means you’ll get an interface developed by people like you.

With a full range of solutions and accessories, TARUS can custom engineer solutions to fit seamlessly into the most demanding studio environment.

Performance Features


Extremely quiet operation compared to ball screw driven machines via rack and pinion drive.

Nearly silent spindle, liquid cooled.

Increased acceleration rates and elimination of backlash via rack and pinion drive on X,Y and Z axes with dual servo motors.

Advanced monocoque aluminum alloy construction of machine column and milling arm increases performance, stability, and rigidity while reducing weight.

TARUS fork style milling head with direct-absolute angular position delivers perfectly blended adjacent surface patches.

Machine Function


Perfect choice for in-studio milling. Full featured, no compromises, highest performance.

World’s most compact high performance 2-axis TARUS proprietary fork style milling head. Full 5-axis capability in the smallest possible form factor.

Liquid cooled spindle provides nearly silent operation.

3 and 5-axis CNC milling and measuring of design models.

Clay and foam.

Installation Features


Many versatile options:

With or without surface plates.

Very low profile rails contain all running hardware plus AC power.

Install above floor or in trenches.

Modular rails, standard section length of 118″ / 3,000 mm. Custom rails and lengths available.

Multiple columns can be added to rail installation as needed.

Versions


Claymill (rail-mounted)

Claymill M (mobile/portable)

Claymill T (taller/larger volume)


CNC Features


Claymill comes with the industry standard Siemens SINUMERIK ONE based TARUS DS with Design Studio Interface and TPI CAM.

Our proprietary TARUS Design Studio Interface and TPI CAM interface is continually developed in partnership with design studios and renowned by car modellers worldwide.

Wireless probing for model alignment and measurement.

Image 1, 2, 3, 5 & banner credits: General Motors
